| Pressure connection: |
Measuring connection M16,
max. 315 bar (Minimess) |
| Suction connection: |
Screw connection 6 L,
max. 10 bar (140 psi) |
| Return line: |
Screw connection 6 L |
| Pressure fluctuation: |
permissible |
| Medium: |
hydraulic fluids, fuels, water,
provided the fluid is
optically homogenous |
| Viscosity range: |
max. 500 mm2,
on suction side max. 100 mm2/s |
| Temperature range: |
Ambience: 0 to 50 °C;
Fluid: 0 to 80 °C |
| Sensor flow rate: |
40 ml/min |
| Flushing volume flow: |
40 ml/min |
| Measuring volume: |
10 to 100 ml,
adjustable (10 ml steps) |
| Volume prior to counting: |
10 to 50 ml,
adjustable in (10 ml steps) |
| Counting time: |
15 s |
| Cycling time: |
1 to 99 min |
| Sensor: |
Laser diode sensor |
| Number of channels = 12: |
2/>5/>15/>25/>50/>100 µm
acc. ISO 4406: 1987 (extended)
>4/>6/>14/>21/>38/>70 µm(c)
acc. ISO 4406: 1999 |
| Indication acc. NAS 1638: |
2-5/5-15/15-25/25-50/50-100 µm |
| Measuring range NAS-classes: |
0 to 12 |
| Indication acc. SAE AS 4059: |
>4/>6/>14/>21/>38/>70 µm(c) |
| Measuring range acc. SAE classes: |
000 to 12 |
| Tank volume: |
0.75 l |
| Indication acc. ISO 4406: 1999 |
>4/>6/>14 µm(c) |
| Measuring range ISO classes: |
1 to 24 |
| Calibration: |
acc. ISO 11171: 1999
and ISO 4402 (ACFTD) |
| Power supply: |
115/ 230 VAC; 50/ 60 Hz;
version with accumulator 12 VDC |
| Dimensions: |
400 x 240 x 380 mm |
| Weight: |
approx. 12 kg |
| Subject to technical alteration without prior notice. |
 |
|
